Available Auxiliary Upfitter Swithes From HansPilot
What are the auxiliary switches for?
Auxiliary switches (often called "aux switches" or "AUX") are customizable electrical controls used in vehicles—especially off-road trucks, SUVs, and performance cars—to power aftermarket accessories or additional features.
Primary Uses of Auxiliary SwitchesAftermarket Lighting
Control light bars, fog lights, rock lights, or LED pods.
Example: *"AUX 1" for roof-mounted spotlights, "AUX 2" for grill-mounted floodlights.*
Winches & Recovery GearPower winches, air compressors, or electronic locking differentials.
Often wired to high-current circuits (e.g., 30–40 amps).
Off-Road AccessoriesOperate air suspension systems, hydraulic jacks, or camping gear (e.g., fridge/freezers).
Performance UpgradesManage nitrous oxide systems, turbo timers, or cooling fans.
Convenience FeaturesPower inverters, CB radios, or dash cams without tapping into factory wiring. cuselectrical c
Where are the auxiliary switches?
The location of auxiliary switches (aux switches) depends on whether they're factory-installed or aftermarket. Here’s where to look in common setups of HansPilot products:
1. Jeep Wrangler/Gladiator (JL/JT)Location: Overhead console (near sun visors)
Layout: 6 switches labeled AUX 1–AUX 6 Amperage: 30A (AUX 1–6)
2. Ford F-150/Raptor
Location: Lower dashboard Overhead console (near sun visors)
Layout: 6 switches (AUX 1–6) with backlighting Amperage: 30A3. Toyota 4Runner/Tacoma TRD Pro
Location: Center console (near gear shifter)
Layout: 6 switches (AUX 1–6) with backlighting Amperage: 30A
4. RAM Trucks
Location: Overhead console or lower dash
Layout: 6 switches (AUX 1–6) with backlighting Amperage: 30A
How do I use the aux switches in my Bronco?
Well,once they’re wired up, you just flip the switch in order to power the accessory that you’ve assigned to that switch. When engaged, the switches will illuminate. The power will be coming from the battery so it’s best to have the engine running when using accessories so that you don’t come back to a dead battery.
Carefully engineered Car level material ensure reliable performance in automotive auxiliary switches.
Choices for optimum performance
- Carefully engineered capacitors and resistors ensure reliable performance in automotive auxiliary switches, delivering stable power delivery and noise-free operation even in demanding conditions.
- – Filter electrical noise for clean switching transitions – Withstand extreme temperatures (-40°C to +125°C) – Prevent voltage spikes that could damage sensitive electronics
- – Maintain consistent current flow across all operating conditions – Tight tolerance (±1%) ensures accurate voltage division – Low thermal drift for stable performance in engine bay environments
IP66 Waterproof Relay Box for Automotive Applications
- Engineered for harsh environments, our IP66-rated relay box delivers:
- Total dust resistance (IP6X) – Sealed against off-road debris
- Powerful water jets defense (IPX6) – Withstands pressure washing
- Vibration-proof construction – Rubber-isolated mounting points
- Temperature-resistant relays (-40°C to +85°C continuous)
OEM Style Design
- Factory-Matched Design
- Direct plug-and-play integration with Bronco’s CANBUS system
- OEM-grade materials: Same tactile switches as Ford’s upfitter controls
- Perfect switches alignment: Precision-molded bezel for blank switch panel
Install and ready for use: No Software Update Required
- ✔ No Software Updates Needed – Just install, and it’s ready to use!
- ✔ Dealership-Free – No ECU flashes or activation required.
- ✔ Premium & Economical – Run 6+ auxiliary switches seamlessly, just like factory setups.
- ✔ DIY-Friendly – Be your own home mechanic—no complicated setups!
- Upgrade your rig with HansPilot’s hassle-free switch solution today!
Install and ready for use: No Software Update Required
- ✔ No Software Updates Needed – Just install, and it’s ready to use!
- ✔ Dealership-Free – No ECU flashes or activation required.
- ✔ Premium & Economical – Run 6+ auxiliary switches seamlessly, just like factory setups.
- ✔ DIY-Friendly – Be your own home mechanic—no complicated setups!
- Upgrade your rig with HansPilot’s hassle-free switch solution today!
Ready for extra lights, winches and other available aftermarket accessories.
Plug-and-play installation preserves factory wiring; direct vehicle integration ensures safe and reliable operation.
"Elevates Driving Experience | Superb Expandability | Multiple Device Support"
One-touch control for interior lights, car refrigerators, air compressors, grille daytime running lights (DRLs), spot lights, and more.
Multi-Zone Off-Road Lighting Command
Independent control for LED light bars (e.g., Baja Designs), fog lamps, rock lights, and chase pods. Enables staged activation: Zone 1 (ditch lights) | Zone 2 (roof bar) | Zone 3 (rear work lights). IP66-rated switches withstand dust/water ingress
Heavy-Duty Winch Management System
Dedicated 30A circuit engineered for high-torque winches (e.g., Warn Zeon, Smittybilt). Features instant ON/OFF control for critical recovery operations.
Smart Trailer Systems Integration
Direct-wire control for trailer brake controllers (e.g., Tekonsha P3), reverse guide lamps, and safety chains. Voltage-stabilized circuit (9-16V input) prevents flickering. Syncs with OEM trailer brake module for seamless towing.
